AS-2TC300 - 200VA 300V Tube Transformer

$60.00
00001456
6.00 LBS
Calculated at checkout
20
Quantity:

Product Description

High-Performance 200VA Toroidal Audio Power Transformer

Designed for superior audio performance, this 200VA toroidal power transformer features a static shield between the primary and secondary windings to enhance isolation and reduce noise interference. Compatible with all standard 115V or 230V power systems at 50Hz or 60Hz, it’s engineered for global use.

Built with heavier gauge copper wires than standard requirements, it minimizes power loss even under full load. A magnetic shield surrounds the outside to reduce stray magnetic fields, improving performance in sensitive audio applications.

With a dielectric strength of over 3500V between the primary and secondary coils, it offers robust electrical insulation. When used with a 60Hz power source, this transformer can safely deliver up to 20% more power than its rated capacity.

Includes a rubber mounting pad and all necessary hardware. This model is similar to the AS-2T300, but includes a center tap for additional flexibility.

  • Product Brief

  • Weight: 6lb
  • Dimensions: 4.9" d x 2.5" h


Electrical Characteristics

Outputs 4x
Power 200VA
Output Voltage  Current
300V 0.33A
300V 0.33A
6.3V 4A
6.3V 4A
